The GCD-4LCF blade provides four analog (SLIU) extension ports or eight analog (SLIU) extension ports (used for on-premise analog telephones, fax machines, and analog modems). The GCD-4LCF are not rated for OPX use. A GCD-4DIOPA blade should be used instead (it supports the analog DID and single line telephone interface functions, such as Off-Premise Extensions).

•  One extension status LED  One blade status LEDs  Constant current type battery feeding (25mA/-27Vdc)  Feeding Polarity Reverse Ability  Connector for GPZ-4LCF Daughter Board  Ring Generator (16Hz, 75Vrms, -10Vdc)  Caller ID Sending Ability  Message Wait Lamp Ability (-110Vdc)

The GCD-4LCF consumes eight ports ranging between ports 1~1536.
The J3 and J4 connectors each provide connection to four analog station ports. The Jx connectors are not polarity sensitive.

---

Необходимые лицензии
SV8100/SV9100: SV8300/SV9300:	- / BE114042 BE106616 / BE114009		8 8

---

Комплектация
	Карта GCD-4LCF		1
Размеры упаковки (ВхШхГ), мм			25х240x195
Вес с упаковкой, кг			0.17
